Economic high rejection PES filter core adopts advanced technology to produce PES membrane independently,which has the performance of high throughput, long life, high bubble point and high rejection rate. The absolute filtration efficiency is over 99.8%,The filter element has good heat resistance and can withstand multiple steam sterilization,The integrity test before delivery ensures the high quality of products.
  • Product features
  • High throughput, high bubble point, strong sterilization High hydrophilicity, easy for wetting test Absolute pore size to ensure effective filtration Each filter element passes the integrity test Broad chemical compatibility
  • Industry Application
  • Electronic industry: terminal filtration of high purity chemicals. Pharmaceutical industry: sterilization and filtration of water for injection, cleaning solution, disinfectant, large quantities of liquid medicine, and pre filtration of liquid medicine. Chemical industry: chemical reagents and other terminal filtration.
  • DOWNLOAD
  • INQUIRY NOW
PRODUCT DESCRIPTION
  • Operating conditions
  • Operating temperature: ≤80℃
  • Maximum pressure difference that can withstand: 4bar (21℃)/2.4bar (80℃)
  • Sterilization method: 121℃/30min steam sterilization
  • Material structure
  • Filter material: Inlet asymmetry PES
  • Inner core: PP
  • shell: PP
  • End cap: PP
  • Sealing technology: hot melt welding
  • Gasket/O-ring: EPDM, silica gel, fluororubber, PTFE coated, PTEF
  • Filter element size
  • external diameter: (68mm)
  • length: 5〞、10 〞、20 〞、30〞、40〞
Ordering Information
  • Series
  • EGPS
  • Micron Rating
  • 010=0.10μm
  • 022=0.22μm
  • 045=0.45μm
  • 100=1.00μm
  • 300=3.00μm
  • 500=5.00μm
  • End cap type
  • J1=222/Fin
  • J2=222/Flat
  • J3=226/Fin
  • J4=226/Flat
  • J5=DOE
  • Length
  • 05=5"
  • 10=10"
  • 20=20"
  • 30=30"
  • 40=40"
  • O-ring
  • S=Silicone
  • E=EPDM
  • V=Viton
  • D=PTFE
  • core
  • A=PP core
  • B=PP core+Interface lined with stainless steel
  • C=PP core+Lined with stainless steel
