The low diffusion flow polyethersulfone filter element adopts imported PES membrane, which has the performance of ultra-low diffusion flow, low protein adsorption and high rejection rate.The filter element has good heat resistance and can withstand multiple steam sterilization,The integrity test before delivery ensures the high quality of products.
  • Product features
  • Ultra-low diffusion flow Asymmetric double-layer polyethersulfone membrane, high pollution capacity Absolute pore size to ensure effective filtration Each filter element passes the integrity test Broad chemical compatibility
  • Industry Application
  • food industry: Sterilization and filtration of pure draft beer, wine, pure water, mineral water, etc. Pharmaceutical industry: Sterilization and filtration of water for injection, large volume parenteral (LVP), small volume parenteral (SVP), freeze-dry powder injection, biological products, eye drops, antibiotics, etc.
PRODUCT DESCRIPTION
  • Operating conditions
  • Operating temperature: ≤80℃
  • Maximum pressure difference that can withstand: 4bar (21℃)/2.4bar (80℃)
  • Sterilization method: 121℃/30min steam sterilization
  • Material structure
  • Filter material: Inlet asymmetry PES
  • Inner core: PP
  • shell: PP
  • End cap: PP
  • Sealing technology: hot melt welding
  • Gasket/O-ring: EPDM, silica gel, fluororubber, PTFE coated, PTEF
  • Filter element size
  • external diameter: (68mm)
  • length: 5〞、10 〞、20 〞、30〞、40〞
Ordering Information
  • Series
  • EHPS
  • Micron Rating
  • 010=0.10μm
  • 022=0.22μm
  • 045=0.45μm
  • 065=0.65μm
  • 080=0.80μm
  • 120=1.20μm
  • End cap type
  • J1=222/Fin
  • J2=222/Flat
  • J3=226/Fin
  • J4=226/Flat
  • J5=DOE
  • Length
  • 05=5"
  • 10=10"
  • 20=20"
  • 30=30"
  • 40=40"
  • O-ring
  • S=Silicone
  • E=EPDM
  • V=Viton
  • D=PTFE
  • core
  • A=PP core
  • B=PP core+Interface lined with stainless steel
  • C=PP core+Lined with stainless steel

  • related products
