Backwashable string wound filter cartridges E70D-L Series

E70D-L series string wound filter cartridges are generally used in the condensate polishing system of power plants. The condensate polishing powder resin covered filter requires stable operation at a relatively high temperature. Its high strength can fully withstand the instantaneous high-pressure impact generated during resin bursting and backwashing. The filter cartridge is controlled by computer, and it is made by winding PP cotton thread or absorbent cotton thread precisely on 304 stainless steel porous skeleton. Ensure that the filter cartridge does not deform, avoid fiber shedding, and ensure the safe operation of the system.

Product features
High mechanical strength can withstand high filtration pressure
Fiber special process to effectively avoid fiber shedding
Stainless steel inner support can withstand higher temperature
Low initial pressure difference and high flow rate
Wide range of standard connectors available

Industry Application
The thermoelectric industry
Boiler make-up water system
Stator cooling water system
Condensate finishing system
Heat network backwater treatment system
New Energy
Production of battery slurry
Petrochemistry
Chemical paint
Paint production
Oil is injected with water
Treatment of produced water
Condensate treatment process

DOWNLOAD
INQUIRY NOW

PRODUCT DESCRIPTION

Length:
60"(1524mm)、70"(1778mm)

Outer diameter:
50mm、64mm

Filter material:
Polypropylene(PP)、Absorbent cotton、Glass fiber (GF)

Skeleton stainless steel:
( 304/316L )

Design flow:
8-9 m³/h

Connector:
Bottom structure:M33 * 1.5 connecting thread/ M33 * 1.5 connecting thread / G33 * 2 connecting thread ( 60 " ) Top structure:M8 thread/ M10 thread/ M6 thread ( 60 " )
